EKKO Forklift (LPG) 10,000 lbs cap, 185" Lift Height
EK50LP
The EKKO EK50LP Liquid Propane 4 Wheel Forklift is designed to be used for all your material handling demands, warehousing, and distribution.
This unit is manufactured with high durable quality, Tier 4 EPA compliant with the Kubota engine and competitive pricing.
- Multifunction instrument panel - motoring for Safety and efficient operation
- Operator compartment- nonslip entrance step, wider access & leg room.
- Adjustable steering column limiting operator arm and shoulder fatigue.
- Excellent Operator visibility.
- Integral Heavy-Duty Chassis- ensuring driver protection
- Steer axle pivots to 80 degrees for tighter turning radius.
- Hydraulic controls
SPECIFICATIONS
|
Model
|
EK50LP |
|
Drive Type
|
LPG |
|
Type of Operation
|
Propane |
|
Load Capacity
|
10,000 LBS |
|
Load Center
|
24 in |
|
Lift Height
|
185 in |
|
Wheelbase
|
61.8 in |
|
Service Weight
|
16,250 LBS |
|
Tire Material
|
Pattern Cush. Tire |
|
Traction Pin Height
|
11.2 in |
|
Service Brake
|
Hydraulic Foot Pedal |
|
Overall Width
|
55.9 in |
|
Overall Length with Forks
|
157 in |
|
Overall Length without Forks
|
109 in |
|
Min Ground Clearance (at the Mast)
|
4.3 in |
|
Max Traveling Speed (Loaded/Unloaded)
|
10.5/11.2 mph |
|
Mast Overall Height
|
91.9 in |
|
Free Lifting Height
|
44.3 in |
|
Backrest Height (from the surface of the forks)
|
47.6 in |
|
Fork Size
|
48x5.9x1.97 in |
|
Parking Brake
|
Mechanical Hand Lever |
|
Engine Model
|
Kubota WG3800 |
|
Engine Rated Power
|
63.2 HP/rpm |
